Key Selling Points
- Ultra-Compact Design: Weighs only 75g (2.6oz) and fits in tight spaces (51x35x45mm)
- Military-Grade Durability: Operates flawlessly in extreme temperatures and humidity (tested to MIL-STD-810G)
- Adaptive Performance: Adjustable repetition rate (1-10Hz) for dynamic scenarios
- Pinpoint Accuracy: 98% success rate with ≤0.5mrad beam divergence
Applications
- Surveying
- Forestry management
- Drone navigation
- Industrial robotics
- Security surveillance
Specifications
| Laser wavelength | 1535±5nm |
| Maximum measuring range | Under conditions of visibility not less than 10 km and relative humidity not greater than 80%, with moderate atmospheric turbulence and a target reflectivity of 0.2, the maximum detection range for a 2.3 m × 2.3 m target shall be no less than 6 km. |
| Minimum measuring range | ≤30m |
| Ranging accuracy | ≤±1m |
| Repetition frequency | Adjustable from 1 Hz to 10 Hz. |
| Accuracy rate | ≥98% |
| Beam angle | ≤0.5mrad |
| Volume | ≤51×35×45mm |
| Weight | ≤75g |
| Supply voltage | DC 9~15V |
| Operating temperature | -40℃~+60℃ |
| Storage temperature | -50℃~+70℃ |
Note: All performance specifications and interfaces can be customized to meet specific requirements.
